CEE Wandsteckdose, Schraubklemmen, 16A, 3p+E, 380-415 V AC

PKF16W434

Hauptdokumente

Produktdatenblatt Download
Environmental Disclosure Download
Promotional video Video anzeigen
How to video Video anzeigen
CAD Download
Catalog Download
Declaration of Conformity (Sustainability) Download
Offer Marketing Illustration Download
Declaration of conformity Download

Spezifikationen

Hauptmerkmale
Baureihe Mureva
Produkt- oder Komponententyp Sockel
Kurzbezeichnung des Geräts Mureva socket
Stecker/Steckdosen-Kategorie Niederspannung
Beschreibung der Pole 3P + E
Netzwerktyp AC
Ausgangsstandard Industriell
Zusatzmerkmale
Montagemodus Wandmontage
Stecker/Steckdose/Steuerstatus Abgewinkelt
[In] Bemessungsstrom 16 A
[Ue] Bemessungs-Betriebsspannung 380 - 415 V
Netzwerkfrequenz 50/60 Hz
Erd.-Zapf.-Pos. im Uhrzeigers. 6 h
Stecker, Steckdosenmaterial Gehäuse: selbstlöschender Kunststoffwerkstoff
Kontaktmaterial Hülsen: Messing
Anschlüsse - Klemmen Unverlierbare Schrauben
Kabel-Querschnitt 1…4 mm²
äußerer Kabeldurchmesser 21 mm
Gewindetyp M25
Produktgewicht 0,21 kg
Höhe 131 mm
Breite 75 mm
Tiefe 104 mm
Farbe Grau (RAL 7035)
Spannungfarbe Rot
Montage
Normen IEC 60309-2
IEC 60309-1
Schutzart (IP) IP44
Schutzart (IK) IK08 entspricht EN 62262
Feuerbeständigkeit 750 °C entspricht IEC 60695-2-1
Relative Luftfeuchtigkeit 50 % bei 40 °C
70 % bei 30 °C
90 % bei 20 °C
Umgebungstemperatur bei Betrieb 35 °C ( 86400 s )
Schutzart (IP) IP44
Verpackungseinheiten
VPE 1 Art PCE
Anzahl der Geräte pro Packung 1
Verpackungsgewicht (Lbs) 180,800 g
VPE 1 Höhe 7,500 cm
VPE 1 Breite 10,500 cm
VPE 1 Länge 13,000 cm
VPE 2 Art BB1
VPE 2 Menge 8
VPE 2 Gewicht 1,609 kg
VPE 2 Höhe 17,500 cm
VPE 2 Breite 26,000 cm
VPE 2 Länge 27,000 cm
VPE 3 Art S03
VPE 3 Menge 16
VPE 3 Gewicht 3,638 kg
VPE 3 Höhe 30,000 cm
VPE 3 Breite 30,000 cm
VPE 3 Länge 40,000 cm
Vertragliche Gewährleistung
Garantie (in Monaten) 18

Nachhaltigkeit

Nachhaltigkeit
Quecksilberfrei Ja
SCIP-Nummer 89350e0d-a4ac-4516-bf86-fdaed8a227fc
Circular Econmomy-Eignung Keine besonderen Recycling-Verfahren erforderlich
Verpackung ohne Kunststoff Ja
Verpackung mit Recycling-Karton Ja
Rücknahme Nein
CO2-Bilanz (kg CO2 eq.) 8
Sustainable packaging Nein
Total lifecycle Carbon footprint 8 kg CO2 eq.
Carbon footprint of the manufacturing phase [A1 to A3] 1.3770450637726925
CO₂-Fußabdruck der Herstellungsphase [A1 bis A3] 1 kg CO2 eq.
Carbon footprint of the distribution phase [A4] 0.02648407211381254
CO₂-Fußabdruck der Distributionsphase [A4] 0 kg CO2 eq.
CO₂-Fußabdruck der Installationsphase [A5] 0 kg CO2 eq.
Carbon footprint of the use phase [B2, B3, B4, B6] 5.654915492957747
CO₂-Fußabdruck der Nutzungsphase [B2, B3, B4, B6] 6 kg CO2 eq.
Carbon footprint of the end-of-life phase [C1 to C4] 0.6379564236554486
CO₂-Fußabdruck der End-of-Life-Phase [C1 bis C4] 0.6 kg CO2 eq.
EU-RoHS-Richtlinie https://download.se.com/files?p_Doc_Ref=PKF16W434_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
REACh-Verordnung https://download.se.com/files?p_Doc_Ref=PKF16W434_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
Recyclingfähigkeitspotential in % 33
Durchschnittlicher Prozentsatz des recycleten Kunststoffgehaltes 13 %
PVC-frei PVC-freies Produkt
Halogenfrei-Status Produkt mit halogenfreien Kunststoffteilen
PFAS-Verordnung der OECD https://download.se.com/files?p_Doc_Ref=PKF16W434_OECD_PFAS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
POP-Richtlinie https://download.se.com/files?p_Doc_Ref=PKF16W434_POP_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
