Umschaltrelais iRLI, 1W+1S, 10A, 24V AC

A9E15537

Hauptdokumente

Produktdatenblatt Download
CAD Download
Catalog Download
Declaration of Conformity (Sustainability) Download
Offer Marketing Illustration Download

Dieses Produkt ist kompatibel mit


Spezifikationen

Hauptmerkmale
range of product Acti9
Produktname Acti 9 iRLI
Produkt- oder Komponententyp Relais
Kurzbezeichnung des Geräts iRLI
Geräteanwendung Wechselrelais
Zusammensetzung der Signalkontakte 1 C/O + 1 S
[Uc] Steuerkreisspannung 24 V AC 50/60 Hz
Zusatzmerkmale
[Ie] Bemessungs-Betriebsstrom 10 A bei 230 V AC (cos Phi = 1)
[Ui] Bemessungs-Isolationsspannung 250 V AC
Stromversorgung-Halteleistung 4 VA
Versorgung mittlere Anzugsleistung 4 VA
Montagemodus Fest
Montagehalterung 35 mm symmetrische DIN-Schiene
9-mm-Raster 2
Höhe 88 mm
Breite 18 mm
Tiefe 70 mm
Produktgewicht 0,112 kg
Farbe Weiß
Elektrische Lebensdauer AC-21: 100000 Zyklen
Anschlüsse - Klemmen Tunnelklemmen0,5…6 mm²
Montage
Normen NF C 45-250
IEC 255
Schutzart (IP) IP20
Umgebungstemperatur bei Betrieb -5…55 °C
Umgebungstemperatur bei Lagerung -40…70 °C
Verpackungseinheiten
VPE 1 Art PCE
Anzahl der Geräte pro Packung 1
Verpackungsgewicht (Lbs) 116,000 g
VPE 1 Höhe 8,500 cm
VPE 1 Breite 1,700 cm
VPE 1 Länge 7,500 cm
VPE 2 Art BB1
VPE 2 Menge 12
VPE 2 Gewicht 1,440 kg
VPE 2 Höhe 8,500 cm
VPE 2 Breite 9,500 cm
VPE 2 Länge 22,000 cm
VPE 3 Art S03
VPE 3 Menge 144
VPE 3 Gewicht 17,771 kg
VPE 3 Höhe 30,000 cm
VPE 3 Breite 30,000 cm
VPE 3 Länge 40,000 cm
Vertragliche Gewährleistung
Garantie (in Monaten) 18

Nachhaltigkeit

Nachhaltigkeit
Quecksilberfrei Ja
SCIP-Nummer 6763a476-30bc-4d05-a4bb-93f8d65c3771
Frei von giftigen Schwermetallen Ja
Verpackung ohne Kunststoff Ja
Verpackung mit Recycling-Karton Nein
Rücknahme Ja
Circular Econmomy-Eignung Keine besonderen Recycling-Verfahren erforderlich
Silikonfrei Nein
Sustainable packaging Nein
WEEE-Kennzeichnung Das Produkt muss entsprechend bestimmter Hinweise auf Märkten der Europäischen Union entsorgt werden und darf nicht in Haushaltsabfälle gelangen.
EU-RoHS-Richtlinie https://download.se.com/files?p_Doc_Ref=A9E15537_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
Halogenfrei-Status Produkt enthält Halogene über den Grenzwerten
REACh-Verordnung https://download.se.com/files?p_Doc_Ref=A9E15537_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
PFAS-Verordnung der OECD https://download.se.com/files?p_Doc_Ref=A9E15537_OECD_PFAS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
POP-Richtlinie https://download.se.com/files?p_Doc_Ref=A9E15537_POP_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
