Thorsman Glands, Kabelverschraubung, grau, M16, Durchmesser 4 bis 8 VPE20Stck
ISM71502
Hauptdokumente
 Produktdatenblatt |
Download |
|
CAE
|
Download |
|
Other technical guide
|
Download |
|
Certificate
|
Download |
|
Declaration of Conformity (Sustainability)
|
Download |
|
Catalog
|
Download |
Dieses Produkt ist kompatibel mit
Boxen: Kompatible Produkte
Boxen (6)
Spezifikationen
| Hauptmerkmale | |
|---|---|
| Produktpalette | Thorsman Glands |
| Produkttyp | Kabelverschraubung |
| Farbe | Grau (RAL 7035) |
| Menge pro Packung | Satz à 20 Stück | Zusatzmerkmale |
| Material | PA6 |
| ISO-Gewinde | M16 |
| äußerer Kabeldurchmesser | 4…8 mm | Montage |
| IP-Klasse | IP68 |
| Betriebstemperatur | -30…80 °C permanent -30…150 °C intermittierend |
Verpackungseinheiten |
| VPE 1 Art | PCE |
| Anzahl der Geräte pro Packung | 1 |
| Verpackungsgewicht (Lbs) | 8,000 g |
| VPE 1 Höhe | 0,800 cm |
| VPE 1 Breite | 15,000 cm |
| VPE 1 Länge | 6,000 cm |
| VPE 2 Art | BB1 |
| VPE 2 Menge | 20 |
| VPE 2 Gewicht | 222,000 g |
| VPE 2 Höhe | 16,000 cm |
| VPE 2 Breite | 15,000 cm |
| VPE 2 Länge | 6,000 cm |
| VPE 3 Art | CAR |
| VPE 3 Menge | 1500 |
| VPE 3 Gewicht | 17,200 kg |
| VPE 3 Höhe | 56,000 cm |
| VPE 3 Breite | 38,000 cm |
| VPE 3 Länge | 30,000 cm | Vertragliche Gewährleistung |
| Garantie (in Monaten) | 18 |
Nachhaltigkeit
Nachhaltigkeit
| Frei von giftigen Schwermetallen | Ja |
Quecksilberfrei
|
Ja |
| Verpackung ohne Kunststoff | Nein |
| Verpackung mit Recycling-Karton | Nein |
| Frei von REACh-SVHC | Ja |
| Rücknahme | Nein |
| Circular Econmomy-Eignung | Keine besonderen Recycling-Verfahren erforderlich |
| Sustainable packaging | Nein |
| EU-RoHS-Richtlinie | https://download.schneider-electric.com/files?p_Doc_Ref=ISM71502_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| REACh-Verordnung | https://download.schneider-electric.com/files?p_Doc_Ref=ISM71502_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
