FI-SCHUKO-Sicherheitssteckdosen-Einsatz mit BRS, anthrazit, System M

232814

Hauptdokumente

Produktdatenblatt Download
Declaration of Conformity (Sustainability) Download
Declaration of conformity Download
User guide Download
Certificate Download
Catalog Download
Technical illustration Download

Spezifikationen

Hauptmerkmale
Baureihe Merten
Produktname System M Inserts
Produkt- oder Komponententyp Steckdose
Gerätedarstellung Mechanismus mit Befestigungsrahmen und Abdeckplatte
Zusatzmerkmale
Gehäusevariante Einbau
Befestigungsmodus Durch Schrauben und Krallen
Geräteanwendung Stromversorgung
Anzahl der Steckdosen 1
Konfiguration der Ausgangspole 2-polig + E
Standardabweichung des Ausgangs Schuko
Ausgangsstandard CEE 7/3
Abdeckungstyp Mit Verschluss
Bemessungsstrom 16 A
[Ue] Bemessungs-Betriebsspannung 250 V
Netzwerktyp AC
Netzwerkfrequenz 50/60 Hz
Schutzart Erdschlussschutz
Kurzschlussschutz
Beschriftung 0 - 1
Farbton Anthrazitfarben (RAL 7024)
Material Thermoplastisch
Oberflächenbeschaffenheit Matt
Anschlüsse - Klemmen Schraubenlose Klemmen
Schutzart (IP) IP20
Breite 71 mm
Höhe 71 mm
Normen DIN 49440
Verpackungseinheiten
VPE 1 Art PCE
Anzahl der Geräte pro Packung 1
Verpackungsgewicht (Lbs) 166,000 g
VPE 1 Höhe 7,700 cm
VPE 1 Breite 7,800 cm
VPE 1 Länge 9,100 cm
VPE 2 Art CAR
VPE 2 Menge 24
VPE 2 Gewicht 4,352 kg
VPE 2 Höhe 19,400 cm
VPE 2 Breite 30,500 cm
VPE 2 Länge 40,500 cm
Vertragliche Gewährleistung
Gewährleistung 18 Monate

Nachhaltigkeit

Nachhaltigkeit
Frei von REACh-SVHC Ja
EU-RoHS-Richtlinie Konform
EU-RoHS-Deklaration
Frei von giftigen Schwermetallen Ja
Quecksilberfrei Ja
Circular Econmomy-Eignung Keine besonderen Recycling-Verfahren erforderlich
Verpackung ohne Kunststoff Nein
Verpackung mit Recycling-Karton Nein
Rücknahme Ja
Sustainable packaging Nein
WEEE Label Das Produkt muss entsprechend bestimmter Hinweise auf Märkten der Europäischen Union entsorgt werden und darf nicht in Haushaltsabfälle gelangen.
