Hauptdokumente
 Produktdatenblatt |
Download |
|
User guide
|
Download |
|
Instruction sheet
|
Download |
|
Certificate
|
Download |
Dieses Produkt ist kompatibel mit
Schnittstellen-Anschlüsse Ersatzbatterien: Kompatible Produkte
Ersatzbatterien (1)
Spezifikationen
| Hauptmerkmale | |
|---|---|
| Main input voltage | 230 V |
| Rated power in W | 410 W |
| Rated power in VA | 650 VA |
| Output connection | 3 IEC 60320 C13 1 IEC 60320 C13 Spitze 2 IEC-Steckbrücken |
| Input frequency | 50/60 Hz +/-5 Hz automatische Erfassung |
| Efficiency at full load | 151 - 302 V einstellbar 160 - 280 V |
| Maximum configurable power in W | 410 W |
| UPS topology | Line Interactive |
| Maximum configurable power in VA | 650 VA |
| Transfer time | 2 ms typisch | Zusatzmerkmale |
| Number of rack unit | 0U |
| Number of cables | 1 |
| Redundant | No |
| Color | Beige |
| Height | 16,8 cm |
| Width | 11,9 cm |
| Depth | 36,8 cm |
| Product weight | 10,68 kg |
| Mounting location | Frontseite |
| Mounting preference | No preference |
| Mounting mode | Nicht Rack-montierbar |
| USB compatible | No |
| Additional information | Konfigurierbar für 220, 230 oder 240 V Nennausgangsspannung |
| Surge energy rating | 290 J |
| Noise filtering | Mehrpolige Geräuschfilterung, 0,3 % IEEE-Überspannschutz, Null-Klemm-Reaktionszeit: Gemäß UL1449 |
| Control panel | LED-Statusanzeige mit On-Line : auf Batteriebetrieb : Batterie und Überlastungsanzeigen ersetzen |
| Alarm | Alarm bei Batteriebetrieb : Dezidierter Alarm bei niedriger Batterieladung : konfigurierbare Verzögerungen |
| Range of product | Back-UPS Pro | Batterien und Überbrückungszeit |
| Battery type | Bleisäurebatterie |
| Typical recharge time | 5,5 h |
| RBC quantity | 1 |
| Battery charging power | 24 W bewertet |
| Battery life | 3…5 Jahre | Montage |
| Product certification | A-Tick C-Tick CE GOST VDE |
| Equipment protection policy | Kompletter Nutzungszeitraum: 100.000 Euro Kompletter Nutzungszeitraum: 50.000 GBP |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 0 - 10.000 ft |
| Ambient air temperature for storage | -15…45 °C |
| Storage relative humidity | 0…95 % |
| Storage altitude | 0…15240 m |
| Acoustic level | 45 dBA |
| Heat dissipation | 70 Btu/h | Verpackungseinheiten |
| Verpackungsgewicht (Lbs) | 12,334 kg |
| VPE 1 Höhe | 22,900 cm |
| VPE 1 Breite | 20,300 cm |
| VPE 1 Länge | 45,700 cm |
| SCC14 | 10731304009969 |
| VPE 1 Art | PCE |
| Anzahl der Geräte pro Packung | 1 | Vertragliche Gewährleistung |
| Garantie (in Monaten) | 12 Batterie|24 USV |
Nachhaltigkeit
Nachhaltigkeit
| Sustainable packaging | Nein |
| Austauschbare Batterie | Nein |
17 Dokumente
| Instalación y funcionamiento de Back-UPS 280/420/650 (salidas IEC-Internacional) 15/03/25 · User guide | 0,1 MB | Download |
Onduleur Back-UPS 230 V (fiche)
 15/03/25 · User guide |
0,0 MB | Download |
| Guide de sécurité de l'onduleur Smart-UPS - Smart-UPS et Back-UPS (fiche)
15/03/25 · User guide |
0,1 MB | Download |
| Guida alla sicurezza per Smart-UPS - Smart-UPS e Back-UPS (Scheda)
15/03/25 · User guide |
0,1 MB | Download |
| Guía de seguridad de Smart-UPS-Smart-UPS y Back-UPS (hoja) 15/03/25 · User guide | 0,1 MB | Download |
| VDE GS certification mark
15/03/25 · Certificate |
0,3 MB | Download |
| Back-UPS 280/420/650 (IEC Outlets - Intl) Installation and Operation 15/03/25 · User guide | 0,1 MB | Download |
| Back-UPS 230 V (Sheet) 15/03/25 · User guide | 0,0 MB | Download |
| Smart-UPS Safety Guide - Smart-UPS & Back-UPS (Sheet) 15/03/25 · Instruction sheet | 0,2 MB | Download |
| Back-UPS 230 V (Infoblatt)
15/03/25 · User guide |
0,0 MB | Download |
| Smart-UPS Sicherheitsleitfaden – Smart-UPS und Back-UPS (Infoblatt)
15/03/25 · User guide |
0,1 MB | Download |
| Back-UPS 280/420/650 (IEC-Steckdosen – international), Installation und Bedienung 15/03/25 · User guide | 0,1 MB | Download |
| Installation et utilisation de l’onduleur Back-UPS 280/420/650 (prises CEI - Intl) 15/02/25 · User guide | 0,2 MB | Download |
| Back-UPS de 230 V (hoja)
15/02/25 · User guide |
0,0 MB | Download |
| Back-UPS 230 V (Scheda)
15/02/25 · User guide |
0,0 MB | Download |
| Back-UPS 280/420/650 (uscite IEC - internazionali) - Installazione e uso 19/01/25 · User guide | 0,1 MB | Download |
| CB Report,VDE Safety Approval
19/01/25 · Certificate |
35,6 MB | Download |
