Aus-Kontrollschalter-Einsatz, 2-polig, 10 AX, AC 250 V, Steckklemmen

MEG3102-0000

Hauptdokumente

Produktdatenblatt Download
Declaration of Conformity (Sustainability) Download
Technical illustration Download
Catalog Download
Certificate Download
Declaration of conformity Download
Environmental Disclosure Download

Dieses Produkt ist kompatibel mit

Wippen (68)

Spezifikationen

Hauptmerkmale
Baureihe Merten
Produkt- oder Komponententyp Schalter
Geräteanwendung Beleuchtung
Gerätedarstellung Mechanismus mit Befestigungsrahmen
Typ der Technologie Elektromechanisch
Gehäusevariante Einbau
Anzahl der Wippen 1
Stellglied Wippe
Zusatzmerkmale
Schalterfunktion 2-polig 1-polig
Lokale Signalisierung LED
Signalisierungsfunktion Anzeige
[Ue] Bemessungs-Betriebsspannung 250 V
Netzwerktyp AC
Bemessungsstrom 10 AX
Anschlüsse - Klemmen Schraubenlose Klemmen
Befestigungsmodus Durch Schrauben und Krallen
Montage
Schutzart (IP) IP20
Verpackungseinheiten
VPE 1 Art PCE
Anzahl der Geräte pro Packung 1
Verpackungsgewicht (Lbs) 62,000 g
VPE 1 Höhe 3,500 cm
VPE 1 Breite 7,100 cm
VPE 1 Länge 7,200 cm
VPE 2 Art BB1
VPE 2 Menge 10
VPE 2 Gewicht 740,000 g
VPE 2 Höhe 9,500 cm
VPE 2 Breite 18,200 cm
VPE 2 Länge 27,700 cm
VPE 3 Art CAR
VPE 3 Menge 60
VPE 3 Gewicht 4,898 kg
VPE 3 Höhe 30,900 cm
VPE 3 Breite 33,600 cm
VPE 3 Länge 40,600 cm
Vertragliche Gewährleistung
Gewährleistung 18 Monate

Nachhaltigkeit

Nachhaltigkeit
EU-RoHS-Richtlinie Konform mit Ausnahmen
EU-RoHS-Deklaration
Quecksilberfrei Ja
Circular Econmomy-Eignung Keine besonderen Recycling-Verfahren erforderlich
SCIP-Nummer 8baa1bd8-8da4-4d84-953d-349bb0677982
Verpackung ohne Kunststoff Ja
Verpackung mit Recycling-Karton Ja
Rücknahme Nein
CO2-Bilanz (kg CO2 eq.) 3
Sustainable packaging Ja
Total lifecycle Carbon footprint 3 kg CO2 eq.
Carbon footprint of the manufacturing phase [A1 to A3] 0.2922431560293337
CO2 Fußabdruck am Ende der Betriebsdauer ​ 0.3 kg CO2 eq.
Carbon footprint of the distribution phase [A4] 0.03301311339281254
Durchschnittlicher Prozentsatz der ReponsibleSteel zertifizierten Metalle 0 kg CO2 eq.
Carbon footprint of the installation phase [A5] 0.011812281485040646
CO2 Fußabdruck während der Einrichtung 0 kg CO2 eq.
Carbon footprint of the use phase [B2, B3, B4, B6] 2.9086830927585203
Carbon footprint of the use phase [B2, B3, B4, B6] 3 kg CO2 eq.
Carbon footprint of the end-of-life phase [C1 to C4] 0.13915129835238732
Carbon footprint of the end-of-life phase [C1 to C4] 0.1 kg CO2 eq.
Durchschnittlicher Prozentsatz des recycleten Kunststoffgehaltes 45 %
WEEE Label Das Produkt muss entsprechend bestimmter Hinweise auf Märkten der Europäischen Union entsorgt werden und darf nicht in Haushaltsabfälle gelangen.
