Adapterplatine für eSM-Sicherheitskarte an LXM32M
VW3M8810
Materialpreisgruppe
: C8
Hauptdokumente
 Produktdatenblatt |
Download |
|
User guide
|
Download |
|
Catalog
|
Download |
|
CAD
|
Download |
|
Declaration of Conformity (Sustainability)
|
Download |
Spezifikationen
| Hauptmerkmale | |
|---|---|
| Baureihe | Lexium Altivar |
| Zubehör / Teilekategorie | Anschlusszubehör |
| Produkt- oder Komponententyp | ESM Verteilereinheit |
| Kompatible Produktfamilie | Lexium 32 Altivar Prozess ATV900 |
| Produktkompatibilität | LXM32 ATV930 ATV950 |
| Zubehör / Zielkategorie | Einfacher Anschluss von bis zu 5 eSM-Sicherheitskarten im Schaltschrank | Zusatzmerkmale |
| Montagehalterung | DIN-Schiene |
| Breite | 78 mm |
| Länge | 136 mm | Verpackungseinheiten |
| VPE 1 Art | PCE |
| Anzahl der Geräte pro Packung | 1 |
| VPE 1 Höhe | 9,400 cm |
| VPE 1 Breite | 17,200 cm |
| VPE 1 Länge | 24,400 cm |
| Verpackungsgewicht (Lbs) | 326,000 g |
| VPE 2 Art | S04 |
| VPE 2 Menge | 12 |
| VPE 2 Höhe | 30,000 cm |
| VPE 2 Breite | 40,000 cm |
| VPE 2 Länge | 60,000 cm |
| VPE 2 Gewicht | 4,718 kg | Vertragliche Gewährleistung |
| Garantie (in Monaten) | 18 |
Nachhaltigkeit
Nachhaltigkeit
Quecksilberfrei
|
Ja |
| Verpackung ohne Kunststoff | Nein |
| Verpackung mit Recycling-Karton | Ja |
| Frei von REACh-SVHC | Ja |
| PVC-frei | Ja |
| Rücknahme | Ja |
| Sustainable packaging | Nein |
| EU-RoHS-Richtlinie | https://download.se.com/files?p_Doc_Ref=VW3M8810_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| REACh-Verordnung | https://download.se.com/files?p_Doc_Ref=VW3M8810_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
