APC Back-UPS Pro, 2200VA/1320W, Tower, 230V, 3x Universal- und 3x IEC C13-Ausgänge, RGB-Beleuchtung, reine Sinuswelle, Midnight (Schwarz)
BGM2200B-MSX
Hauptdokumente
 Produktdatenblatt |
Download |
|
Brochure
|
Download |
|
User guide
|
Download |
|
Promotional video
|
Video anzeigen |
|
Certificate
|
Download |
|
Circularity Profile
|
Download |
|
Declaration of Conformity (Sustainability)
|
Download |
|
Environmental Disclosure
|
Download |
Dieses Produkt ist kompatibel mit
Ersatzbatterien: Kompatible Produkte
Ersatzbatterien (1)
Softwares Spezifikationen
| Hauptmerkmale | |
|---|---|
| Main input voltage | 230 V AC 1 Phase |
| Other input voltage | 230 V |
| Output voltage | 230 V AC 1 Phase |
| Rated power in W | 1320 W |
| Rated power in VA | 2200 VA |
| Input connection | NEMA 5-15P |
| Output connection | 3 IEC 60320 C13 Spitze 3 universal Spitze |
| Input frequency | 50/60 Hz +/-3 Hz |
| Plug standard | C19/C21 |
| Efficiency at full load | 168 - 302 V |
| Maximum input current | 12 A |
| Switching current capacity | 15 A |
| Input harmonic distortion | Weniger als 3 % bei Volllast |
| Input protection | Circuit breaker |
| Maximum configurable power in W | 1320 W |
| Output frequency | 50/60 Hz +/-3 Hz Netzsynchronisation |
| UPS topology | Line-Interactive |
| Waveform type | Sinuswelle |
| Full load runtime | 00:30:00 |
| Half load runtime | 00:04:19 |
| Maximum configurable power in VA | 2200 VA |
| Transfer time | 8 ms typisch, 10 ms max. |
| Type of USB power supply | USB Typ A + C | Zusatzmerkmale |
| Product or component type | Unterbrechungsfreie Stromversorgung |
| Cable length | 1,5 m |
| Number of cables | 1 |
| Additional specification | Gaming performance |
| Redundant | No |
| Color | Schwarz |
| Height | 292,1 mm |
| Width | 104,14 mm |
| Depth | 408,94 mm |
| Product weight | 12,2 kg |
| Mounting support | Boden |
| Mounting preference | No preference |
| Mounting mode | Nicht Rack-montierbar |
| USB compatible | Yes |
| Mounting position | Vertikal |
| Control panel | Multifunktionale LCD-Status- und Steuerungskonsole |
| Alarm | Alarm bei Batteriebetrieb : Dezidierter Alarm bei niedriger Batterieladung : Überlast-Dauertonalarm |
| Surge energy rating | 1080 J |
| Noise filtering | Mehrpolige vollzeit-geräuschfilterung, 5% überspannungsdurchlässigkeit nach ieee, antwortzeit nullabfangung: verzögerungsfrei |
| Range of product | Back-UPS Pro |
| UPS connectivity | USB-Anschluss |
| Battery type | Blei-Säure internal included |
| Mounting mode | Turm | Batterien und Überbrückungszeit |
| Battery type | Bleisäurebatterie |
| Included battery module | 1 |
| Typical recharge time | 16 h |
| RBC quantity | 1 |
| Battery voltage | 24 V |
| Overcurrent protection | 15 A |
| Battery charging power | 12 W bewertet |
| Battery life | 3…5 Jahre | Montage |
| Product certification | CE CB |
| Equipment protection policy | Kompletter Nutzungszeitraum: 150.000 USD |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % |
| Operating altitude | 0 - 10.000 ft |
| Ambient air temperature for storage | -15…40 °C |
| Storage relative humidity | 0…95 % |
| Storage altitude | 0…3048 m |
| Acoustic level | 45 dBA |
| IP protection | IP20 | Verpackungseinheiten |
| VPE 1 Art | PCE |
| Anzahl der Geräte pro Packung | 1 |
| VPE 1 Höhe | 15,5 cm |
| VPE 1 Breite | 35,5 cm |
| VPE 1 Länge | 48 cm |
| Verpackungsgewicht (Lbs) | 14,82 kg |
| SCC14 | 20731304634823 | Vertragliche Gewährleistung |
| Garantie (in Monaten) | 24 |
Nachhaltigkeit
Nachhaltigkeit
| Verpackung ohne Kunststoff | Nein |
| Verpackung mit Recycling-Karton | Ja |
| Rücknahme | Nein |
| Austauschbare Batterie | Vom Benutzer austauschbar |
| Sustainable packaging | Nein |
| CO2 Fußabdruck am Ende der Betriebsdauer | Energieeffizientes Produkt |
| Total lifecycle Carbon footprint | 528 kg CO2 eq. |
| Carbon footprint of the manufacturing phase [A1 to A3] | 142.00254545454544 |
| CO₂-Fußabdruck der Herstellungsphase [A1 bis A3] | 142 kg CO2 eq. |
| Carbon footprint of the distribution phase [A4] | 1.530501818181818 |
| CO₂-Fußabdruck der Distributionsphase [A4] | 2 kg CO2 eq. |
| CO₂-Fußabdruck der Installationsphase [A5] | 0 kg CO2 eq. |
| Carbon footprint of the use phase [B2, B3, B4, B6] | 382.62545454545455 |
| CO₂-Fußabdruck der Nutzungsphase [B2, B3, B4, B6] | 383 kg CO2 eq. |
| Carbon footprint of the end-of-life phase [C1 to C4] | 1.3499672727272727 |
| CO₂-Fußabdruck der End-of-Life-Phase [C1 bis C4] | 1 kg CO2 eq. |
| CO2-Bilanz (kg CO2 eq.) | 528 |
| EU-RoHS-Richtlinie | https://download.se.com/files?p_Doc_Ref=BGM2200B-MSX_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| REACh-Verordnung | https://download.se.com/files?p_Doc_Ref=BGM2200B-MSX_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| Recyclingfähigkeitspotential in % | 62 |
