APC Smart-UPS On-Line, 3000VA, Rackmontage 2HE, 230V, 6xC13+2xC19 IEC, SmartSlot, verlängerte Laufzeit, mit Schienen-Kit, ohne externe Li-Ion Batterie
SRT3000UXI-LI
Hauptdokumente
 Produktdatenblatt |
Download |
|
Declaration of Conformity (Sustainability)
|
Download |
|
Declaration of conformity
|
Download |
|
User guide
|
Download |
|
Instruction sheet
|
Download |
|
Certificate
|
Download |
|
Certificate (Sustainability)
|
Download |
|
Catalog
|
Download |
|
Firmware
|
Download |
|
Environmental Disclosure
|
Download |
|
Safety Data Sheet (SDS or MSDS)
|
Download |
Dieses Produkt ist kompatibel mit
Batterien: Kompatible Produkte
Batterien (1)
Subscriptions: Kompatible Produkte
Subscriptions (6)
Service Bypass Panel: Kompatible Produkte
Service Bypass Panel (1)
Sensoren: Kompatible Produkte
Sensoren (2)
Montage-Artikel: Kompatible Produkte
Montage-Artikel (2)
Communication Options: Kompatible Produkte
Communication Options (5)
Spezifikationen
| Übersicht | |
|---|---|
| Ausführung | Nicht zur Verwendung durch Verbraucher bestimmt. Hochleistungs-USV-Systeme mit Doppelwandler-Online-Technologie und skalierbarer Autonomiezeit | Hauptmerkmale |
| Main input voltage | 230 V AC 1 Phase |
| Other input voltage | 220 V 240 V |
| Output voltage | 230 V 1 Phase |
| Other output voltage | 220 V 240 V |
| Rated power in W | 2700 W |
| Rated power in VA | 3000 VA |
| Input connection | BS1363A Britisch IEC 60320 C20 Schuko CEE 7 / EU1-16-polig |
| Output connection | 6 IEC 60320 C13 2 IEC 60320 C19 |
| Input frequency | 40 - 70 Hz automatische Erfassung |
| Efficiency at full load | 50 - 150 V 40 % Last 80 - 150 V |
| Maximum configurable power in W | 2700 W |
| Harmonic distortion | Weniger als 2 % |
| Output frequency | 50/60 Hz +/-3 Hz Netzsynchronisation |
| Crest factor | 3:1 |
| UPS topology | On-Line |
| Waveform type | Sinuswelle |
| Bypass type | Integrierter Bypass |
| Maximum configurable power in VA | 3000 VA | Zusatzmerkmale |
| Number of rack unit | 2U |
| Cable length | 1,8 m |
| Number of cables | 1 |
| Provided equipment | CD mit Software Kommunikationskabel Dokumentations-CD Installationsanleitung Abnehmbare Stützfüße USB-Kabel Garantiekarte |
| Additional specification | High density |
| Redundant | No |
| Color | Schwarz |
| Height | 432 mm |
| Width | 85 mm |
| Depth | 508 mm |
| Product weight | 22 kg |
| Mounting preference | No preference |
| Mounting mode | Rack-montiert mit Bausatz |
| USB compatible | Yes |
| Mounting position | Vertikal |
| Free slot | 1 |
| Emergency power off | Ja |
| Surge energy rating | 432 J |
| Alarm | Akustische und sichtbare Alarme : priorisiert nach Schweregrad |
| Product or component type | Unterbrechungsfreie Stromversorgung (USV) |
| Range of product | Smart-UPS On-Line |
| Battery type | Li-Ion (Lithium-Ionen) external sold separately |
| UPS connectivity | Serial port USB port |
| Mounting mode | Aufbau with included kit | Batterien und Überbrückungszeit |
| Battery type | Li-Ion (Lithium-Ionen) |
| Extendable runtime | 1 | Montage |
| Product certification | CE EAC UK PSTI |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % nicht kondensierend |
| Operating altitude | 0 - 10.000 ft |
| Ambient air temperature for storage | -20…50 °C |
| Storage relative humidity | 0…95 % nicht kondensierend |
| Storage altitude | 0…15240 m |
| Acoustic level | 50 dBA |
| Heat dissipation | 317 Btu/h |
| IP protection | IP20 |
| Standard | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Verpackungseinheiten |
| Verpackungsgewicht (Lbs) | 29,6 kg |
| VPE 1 Höhe | 24,6 cm |
| VPE 1 Breite | 74,9 cm |
| VPE 1 Länge | 59,4 cm |
| VPE 1 Art | PCE |
| Anzahl der Geräte pro Packung | 1 | Vertragliche Gewährleistung |
| Garantie (in Monaten) | 60 |
Nachhaltigkeit
Nachhaltigkeit
Quecksilberfrei
|
Ja |
| SCIP-Nummer | 0637234b-27c7-4e32-ae29-543dd4803a99 |
| Verpackung ohne Kunststoff | Nein |
| Verpackung mit Recycling-Karton | Ja |
| Rücknahme | Ja |
| Austauschbare Batterie | Vom Benutzer austauschbar |
| CO2-Bilanz (kg CO2 eq.) | 7631 |
| Total lifecycle Carbon footprint | 7 631 kg CO2 eq. |
| Carbon footprint of the manufacturing phase [A1 to A3] | 349.2446769231 |
| CO₂-Fußabdruck der Herstellungsphase [A1 bis A3] | 349 kg CO2 eq. |
| Carbon footprint of the distribution phase [A4] | 3.8660704615 |
| CO₂-Fußabdruck der Distributionsphase [A4] | 4 kg CO2 eq. |
| CO₂-Fußabdruck der Installationsphase [A5] | 0 kg CO2 eq. |
| Carbon footprint of the use phase [B2, B3, B4, B6] | 7274.7613888205 |
| CO₂-Fußabdruck der Nutzungsphase [B2, B3, B4, B6] | 7 275 kg CO2 eq. |
| Sustainable packaging | Nein |
| Carbon footprint of the end-of-life phase [C1 to C4] | 3.4065526154 |
| CO₂-Fußabdruck der End-of-Life-Phase [C1 bis C4] | 3 kg CO2 eq. |
| WEEE-Kennzeichnung | Das Produkt muss entsprechend bestimmter Hinweise auf Märkten der Europäischen Union entsorgt werden und darf nicht in Haushaltsabfälle gelangen. |
| EU-RoHS-Richtlinie | https://download.se.com/files?p_Doc_Ref=SRT3000UXI-LI_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| REACh-Verordnung | https://download.se.com/files?p_Doc_Ref=SRT3000UXI-LI_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| Recyclingfähigkeitspotential in % | 65 |
