APC Smart-UPS 5000VA/208 V Rackmount/Tower

SUA5000RMT5U
APC Brand
Lieferbar solange Restbestän…
Der Service wird eingestellt am:  31. December 2030
EAN Code: 0731304255338

Hauptdokumente

Produktdatenblatt Download
Declaration of Conformity (Sustainability) Download
Circularity Profile Download
User guide Download
Instruction sheet Download
Certificate Download
Catalog Download
Firmware Download
Environmental Disclosure Download
Safety Data Sheet (SDS or MSDS) Download
Quick start guide Download

Dieses Produkt ist kompatibel mit


Spezifikationen

Übersicht
Ausführung Nicht zur Verwendung durch Verbraucher bestimmt. Intelligenter und effizienter Stromversorgungsschutz im Netzwerk mit skalierbarer Laufzeit. Ideal für Server, POS-Systeme, medizinische und Netzwerkgeräte.
Hauptmerkmale
Main input voltage 208 V AC 1 Phase
Output voltage 208 V AC 1 Phase
Rated power in W 4000 W
Rated power in VA 5000 VA
Input connection NEMA L6-30P
Output connection 2 NEMA L6-20R
2 NEMA L6-30R
Efficiency at full load 131 - 268 V einstellbar
141 - 255 V
Input frequency 50/60 Hz +/-5 Hz manueller Schalter
Harmonic distortion Weniger als 5 % bei Volllast
Maximum configurable power in VA 5000 VA
Maximum configurable power in W 4000 W
Transfer time 2 ms typisch, 4 ms max.
UPS topology Line Interactive
Waveform type Sinuswelle
Output frequency 47 - 53 Hz für 50 Hz Nominal Netzsynchronisation
57 - 63 Hz für 60 Hz Nominal Netzsynchronisation
Zusatzmerkmale
Number of rack unit 5U
Cable length 2,4 m
Number of cables 1
Provided equipment CD mit Software
Rack-Montage-Tragschienen
Smart UPS Signalisierungskabel RS-232
Benutzerhandbuch
Web/SNMP-Managementkarte
Redundant No
Color Schwarz
Height 222 mm
Width 483 mm
Depth 660 mm
Product weight 97,73 kg
Mounting location Frontseite
Mounting preference Niedriger
Mounting mode Aufbau
USB compatible No
Control panel LED-Statusanzeige mit Lade- und Batteriebalkenanzeige und On-Line: Batterie Ein: Ersatzbatterie: und Überlastanzeige
Emergency power off Optional
Preinstalled device Network management card
Surge energy rating 480 J
Noise filtering Mehrpolige Geräuschfilterung, 0,3 % IEEE-Überspannschutz, Null-Klemm-Reaktionszeit: Gemäß UL1449
Alarm Alarm bei Batteriebetrieb : Dezidierter Alarm bei niedriger Batterieladung : konfigurierbare Verzögerungen
Product or component type Unterbrechungsfreie Stromversorgung (USV)
Range of product Smart-UPS
Mounting mode Aufbau with included kit
UPS connectivity Serial port
USB port
Available expansion slot
Battery type Lead-acid internal included
Batterien und Überbrückungszeit
Battery type Bleisäurebatterie
Typical recharge time 3 h
RBC quantity 2
Battery life 3…5 Jahre
Battery charging power 542 W bewertet
Montage
Product certification CSA
Equipment protection policy Kompletter Nutzungszeitraum: 150.000 USD
Acoustic level 53 dBA
Heat dissipation 344 Btu/h
Operating altitude 0 - 10.000 ft
Ambient air temperature for operation 0…45 °C
Ambient air temperature for storage -5…55 °C
Storage altitude 0…15240 m
Relative humidity 0…95 %
Storage relative humidity 0…95 %
Verpackungseinheiten
Verpackungsgewicht (Lbs) 106,82 kg
VPE 1 Höhe 63,5 cm
VPE 1 Breite 76,2 cm
VPE 1 Länge 61 cm
VPE 1 Art PCE
Anzahl der Geräte pro Packung 1
Vertragliche Gewährleistung
Garantie (in Monaten) 24

Nachhaltigkeit

Nachhaltigkeit
Quecksilberfrei Ja
Verpackung ohne Kunststoff Nein
Verpackung mit Recycling-Karton Ja
Rücknahme Ja
Austauschbare Batterie Vom Benutzer austauschbar
CO2-Bilanz (kg CO2 eq.) 9143
Total lifecycle Carbon footprint 9 143 kg CO2 eq.
Carbon footprint of the manufacturing phase [A1 to A3] 3655.3729251893
CO₂-Fußabdruck der Herstellungsphase [A1 bis A3] 3 655 kg CO2 eq.
Carbon footprint of the distribution phase [A4] 0.038072123
CO₂-Fußabdruck der Distributionsphase [A4] 0 kg CO2 eq.
Carbon footprint of the installation phase [A5] 43.2594109549
CO₂-Fußabdruck der Installationsphase [A5] 43 kg CO2 eq.
Carbon footprint of the use phase [B2, B3, B4, B6] 5434.296353069
CO₂-Fußabdruck der Nutzungsphase [B2, B3, B4, B6] 5 434 kg CO2 eq.
Sustainable packaging Nein
Carbon footprint of the end-of-life phase [C1 to C4] 10.1352066951
CO₂-Fußabdruck der End-of-Life-Phase [C1 bis C4] 10 kg CO2 eq.
WEEE-Kennzeichnung Das Produkt muss entsprechend bestimmter Hinweise auf Märkten der Europäischen Union entsorgt werden und darf nicht in Haushaltsabfälle gelangen.
REACh-Verordnung https://download.se.com/files?p_Doc_Ref=SUA5000RMT5U_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
EU-RoHS-Richtlinie https://download.se.com/files?p_Doc_Ref=SUA5000RMT5U_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29
Recyclingfähigkeitspotential in % 58
