APC Smart-UPS RT, 1000 VA, 230 V
SURT1000XLI
Lieferbar solange Restbestän…
Der Service wird eingestellt am: 31. December 2027
Eingestellt am: 10. July 2025
EAN Code: 0731304205418
Hauptdokumente
 Produktdatenblatt |
Download |
|
Declaration of Conformity (Sustainability)
|
Download |
|
Warranty
|
Download |
|
Declaration of conformity
|
Download |
|
Instruction sheet
|
Download |
|
Catalog
|
Download |
|
Certificate
|
Download |
|
Firmware
|
Download |
|
User guide
|
Download |
|
Environmental Disclosure
|
Download |
|
Safety Data Sheet (SDS or MSDS)
|
Download |
Dieses Produkt ist kompatibel mit
Service Bypass Panel: Kompatible Produkte
Service Bypass Panel (5)
Sensoren: Kompatible Produkte
Sensoren (2)
Subscriptions: Kompatible Produkte
Subscriptions (6)
Ersatzbatterien: Kompatible Produkte
Ersatzbatterien (1)
Racks: Kompatible Produkte
Racks (5)
Schnittstellen-Anschlüsse: Kompatible Produkte
Schnittstellen-Anschlüsse (8)
Communication Options Batterien: Kompatible Produkte
Batterien (2)
Montage-Artikel: Kompatible Produkte
Montage-Artikel (2)
Spezifikationen
| Übersicht | |
|---|---|
| Ausführung | Nicht zur Verwendung durch Verbraucher bestimmt. Hochleistungs-USV-Systeme mit Doppelwandler-Online-Technologie und skalierbarer Autonomiezeit | Hauptmerkmale |
| Main input voltage | 230 V AC 1 Phase |
| Other input voltage | 220 V 240 V |
| Output voltage | 230 V 1 Phase |
| Other output voltage | 220 V 240 V |
| Rated power in W | 700 W |
| Rated power in VA | 1000 VA |
| Input connection | IEC 60320 C14 |
| Output connection | 6 IEC 60320 2 IEC-Steckbrücken |
| Input frequency | 50/60 Hz +/-5 Hz automatische Erfassung |
| Efficiency at full load | 160 - 280 V |
| Maximum configurable power in W | 700 W |
| Harmonic distortion | Weniger als 3 % |
| Output frequency | 50/60 Hz +/-3 Hz benutzerdefinierbar +/-0,1 Netzsynchronisation |
| Crest factor | 3:1 |
| UPS topology | On-Line |
| Waveform type | Sinuswelle |
| Bypass type | Integrierter Bypass |
| Maximum configurable power in VA | 1000 VA | Zusatzmerkmale |
| Number of rack unit | 2U |
| Number of cables | 1 |
| Provided equipment | CD mit Software Smart UPS Signalisierungskabel RS-232 Benutzerhandbuch |
| Number of power modules | 700 |
| Redundant | No |
| Color | Schwarz |
| Height | 432 mm |
| Width | 85 mm |
| Depth | 483 mm |
| Product weight | 23 kg |
| Mounting location | Frontseite |
| Mounting preference | Niedriger |
| Mounting mode | Nicht Rack-montierbar |
| USB compatible | No |
| Additional information | Konfigurierbar für 220, 230 oder 240 V Nennausgangsspannung |
| Free slot | 1 |
| Emergency power off | Optional |
| Surge energy rating | 420 J |
| Noise filtering | Mehrpolige Geräuschfilterung, 0,3 % IEEE-Überspannschutz, Null-Klemm-Reaktionszeit: Gemäß UL1449 |
| Alarm | Alarm bei Batteriebetrieb : Dezidierter Alarm bei niedriger Batterieladung : Überlast-Dauertonalarm |
| Product or component type | Unterbrechungsfreie Stromversorgung (USV) |
| Range of product | Smart-UPS On-Line |
| Battery type | Lead-acid internal included |
| UPS connectivity | Serial port USB port |
| Mounting mode | Tower | Batterien und Überbrückungszeit |
| Battery type | Bleisäurebatterie |
| Included battery module | 1 |
| Typical recharge time | 3 h |
| RBC quantity | 1 |
| Battery charging power | 109 W bewertet |
| Battery life | 3…5 Jahre |
| Extendable runtime | 1 | Montage |
| Product certification | C-Tick CE GOST VDE |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % nicht kondensierend |
| Operating altitude | 0 - 10.000 ft |
| Ambient air temperature for storage | -20…50 °C |
| Storage relative humidity | 0…95 % nicht kondensierend |
| Storage altitude | 0…15240 m |
| Acoustic level | 50 dBA |
| Heat dissipation | 324 Btu/h |
| IP protection | IP20 |
| Standard | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Verpackungseinheiten |
| Verpackungsgewicht (Lbs) | 27,800 kg |
| VPE 1 Höhe | 28,600 cm |
| VPE 1 Breite | 59,400 cm |
| VPE 1 Länge | 63,000 cm |
| VPE 2 Menge | 4 |
| VPE 2 Breite | 100,000 cm |
| VPE 2 Höhe | 135,000 cm |
| VPE 2 Gewicht | 522,400 kg |
| VPE 2 Art | PAM |
| VPE 2 Länge | 120,000 cm |
| VPE 1 Art | PCE |
| Anzahl der Geräte pro Packung | 1 | Vertragliche Gewährleistung |
| Garantie (in Monaten) | 24 |
Nachhaltigkeit
Nachhaltigkeit
| Verpackung ohne Kunststoff | Nein |
| Verpackung mit Recycling-Karton | Ja |
| Rücknahme | Ja |
| Austauschbare Batterie | Vom Benutzer austauschbar |
| CO2-Bilanz (kg CO2 eq.) | 3651 |
| Total lifecycle Carbon footprint | 3 651 kg CO2 eq. |
| Carbon footprint of the manufacturing phase [A1 to A3] | 343.8300307692 |
| CO₂-Fußabdruck der Herstellungsphase [A1 bis A3] | 344 kg CO2 eq. |
| Carbon footprint of the distribution phase [A4] | 3.8061313846 |
| CO₂-Fußabdruck der Distributionsphase [A4] | 4 kg CO2 eq. |
| CO₂-Fußabdruck der Installationsphase [A5] | 0 kg CO2 eq. |
| Carbon footprint of the use phase [B2, B3, B4, B6] | 3300.4365707493 |
| CO₂-Fußabdruck der Nutzungsphase [B2, B3, B4, B6] | 3 300 kg CO2 eq. |
| Sustainable packaging | Nein |
| Carbon footprint of the end-of-life phase [C1 to C4] | 3.3537378462 |
| CO₂-Fußabdruck der End-of-Life-Phase [C1 bis C4] | 3 kg CO2 eq. |
| WEEE-Kennzeichnung | Das Produkt muss entsprechend bestimmter Hinweise auf Märkten der Europäischen Union entsorgt werden und darf nicht in Haushaltsabfälle gelangen. |
| EU-RoHS-Richtlinie | https://download.se.com/files?p_Doc_Ref=SURT1000XLI_ROHS_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| REACh-Verordnung | https://download.se.com/files?p_Doc_Ref=SURT1000XLI_REACH_DECLARATION&p_enDocType=Declaration+of+Conformity+%28Sustainability%29 |
| Recyclingfähigkeitspotential in % | 65 |
37 Dokumente
| SURT1000XLI REACh-Erklärung
20/03/25 · Declaration of Conformity (Sustainability) |
0,2 MB | Download |
| SURT1000XLI EU-RoHS-Erklärung
20/03/25 · Declaration of Conformity (Sustainability) |
0,2 MB | Download |
| Network Management Card 2 (NMC2) Firmware for Smart-UPS with AP9630/31 15/03/25 · Firmware | 4,3 MB | Download |
| Network Management Card 3 (NMC3) Firmware for Smart-UPS (SU) with AP9640/41/43 15/03/25 · Firmware | 4,2 MB | Download |
| Smart-UPS On-Line 15/03/25 · Catalog | 2,2 MB | Download |
| External Battery Pack SURT48RMXLBP/SURT48RMXLBP2/SURT48XLBP 15/03/25 · User guide | 1,1 MB | Download |
| External Battery Pack SURT48RMXLBP/SURT48RMXLBP2/SURT48XLBP 15/03/25 · User guide | 0,7 MB | Download |
| External Battery Pack SURT48RMXLBP/SURT48RMXLBP2/SURT48XLBP 15/03/25 · User guide | 1,1 MB | Download |
| Smart-UPS RT 1000/2000 VA, 220/230/240 Vac Tower/Rack Mount2U 15/03/25 · User guide | 1,0 MB | Download |
| Smart-UPS RT 1000/2000 VA, 220/230/240 Vac Tower/Rack Mount2U 15/03/25 · User guide | 1,0 MB | Download |
| Smart-UPS RT 1000/2000 VA, 220/230/240 Vac Tower/Rack Mount2U 15/03/25 · User guide | 1,0 MB | Download |
| KCC Certificate of SURT1000
15/03/25 · Certificate |
0,6 MB | Download |
| VDE GS Certification Mark
15/03/25 · Certificate |
2,8 MB | Download |
| UL Listed certification
15/03/25 · Certificate |
0,0 MB | Download |
| TISI certificate for Line Interactive UPS
15/03/25 · Certificate |
0,8 MB | Download |
| Uninteruptible Power Supply (On Line SURT 1/2/3/5/6kVA)
15/03/25 · Certificate |
0,0 MB | Download |
| IRAM for Smart-UPS 15/03/25 · Certificate | 0,1 MB | Download |
| Declaration of Conformity Uninteruptible Power Supply (On Line SURT 1/2/3/5/6kVA)
15/03/25 · Certificate |
0,0 MB | Download |
| VDE CB Certificate SURT1000XLI, SURT1000UXI, SURT1000XLICH, SURT1000UXICH, SURT1000RMXLI, SURT1000RMXLI -NC,SURT1000XLI-NC, SURT1000XLIM, SURT1000XLIX710, SURT1KXI710EL, SURT2000XLI, SURT2000UXI, SURT2000XLICH, SURT2000UXICH, SURT2000XLICHX582, SURT2KXI710EL
15/03/25 · Certificate |
0,1 MB | Download |
| Smart-UPS On-Line Brochure 230V 15/03/25 · Catalog | 0,5 MB | Download |
| Smart-UPS On-Line Brochure 230V 15/03/25 · Catalog | 0,3 MB | Download |
| Smart-UPS RT 1000/2000 VA, 220/230/240 Vac Tower/Rack Mount2U
15/03/25 · User guide |
1,7 MB | Download |
| External Battery Pack SURT48RMXLBP/SURT48RMXLBP2/SURT48XLBP
15/03/25 · User guide |
0,5 MB | Download |
| Installation Smart-UPS Rail Kit
15/03/25 · Instruction sheet |
0,1 MB | Download |
| External Battery Pack SURT48RMXLBP/SURT48RMXLBP2/SURT48XLBP 15/03/25 · User guide | 1,1 MB | Download |
| Smart-UPS RT 1000/2000 VA, 220/230/240 Vac Tower/Rack Mount2U 15/03/25 · User guide | 2,0 MB | Download |
| Smart-UPS RT Tower to SURTRK Rack Conversion (Sheet)
15/03/25 · Instruction sheet |
0,3 MB | Download |
| UK Declaration of Conformity 15/03/25 · Declaration of conformity | 0,5 MB | Download |
| EU Declaration of Conformity-992-0069
15/03/25 · Declaration of conformity |
0,3 MB | Download |
| EU Declaration of Conformity-992-0071
15/03/25 · Declaration of conformity |
0,2 MB | Download |
| UKCA Declaration of Conformity 992-9428
15/03/25 · Declaration of conformity |
0,5 MB | Download |
| Smart-UPS Warranty Registration Card - International
15/03/25 · Warranty |
0,1 MB | Download |
| 01/01/70 Safety Data Sheet (SDS or MSDS) | 0,0 MB | Download |
| 01/01/70 Declaration of conformity | 0,0 MB | Download |
| 01/01/70 Environmental Disclosure | 0,0 MB | Download |
| 01/01/70 User guide | 0,0 MB | Download |
| 01/01/70 User guide | 0,0 MB | Download |
